| S11/13/20/22 Oil-immersed power transformer | |||||||||
| Capacity (KVA) | Voltage Ratio | Vector Group | LWA | No Load Loss (W) | Load Loss At 75 (W) | No Load Current (%) | Impedance 75 (%) | ||
| High Voltage (KV) | HV Tapping % | Low Voltage (KV) | |||||||
| 100 | 6 | ±2×2.5% or +3/-1×2.5% | 0.4 | Dyn11 | 52 | 75 | 1500 | 1 | 4 |
| 125 | 54 | 85 | 1800 | 0.9 | |||||
| 160 | 10 | 100 | 2200 | 0.7 | |||||
| 200 | 56 | 120 | 2600 | 0.7 | |||||
| 250 | 10.5 | 140 | 3050 | 0.7 | |||||
| 315 | 58 | 170 | 3650 | 0.7 | |||||
| 400 | 33 | 200 | 4300 | 0.5 | |||||
| 500 | 60 | 240 | 5150 | 0.5 | |||||
| 630 | 320 | 6200 | 0.3 | 4.5 | |||||
| 800 | 62 | 380 | 7500 | 0.3 | |||||
| 1000 | 450 | 10300 | 0.3 | ||||||
| 1250 | 65 | 530 | 12000 | 0.2 | |||||
| 1600 | 630 | 14500 | 0.2 | ||||||
| 2000 | 67 | 750 | 17400 | 0.2 | 5 | ||||
| 2500 | 900 | 20200 | 0.2 | ||||||
Shandong Lukong Electric Equipment Co., Ltd. (Lukong) was founded in 1984. It is located in Xiajin County on the northwest plain of Shandong Province, on the bank of the ancient Grand Canal with a history of one thousand years. With a registered capital of 50 million yuan and over 30 years of history, the company is mainly engaged in the R&D and manufacturing of high and low voltage electrical equipment supporting the State Grid and 10kV–220kV transformers...[ Read More >>]
